Dry Type Transformer

This transformer is safe, flame-retardant and pollution-free, enabling direct installation at the load center.
It is maintenance-free with simple installation and low comprehensive operating cost.
It features outstanding moisture resistance and can operate normally under 100% relative humidity; no pre-drying is required before restart after shutdown.
With low loss, low partial discharge, low noise and excellent heat dissipation performance, it can operate at 150% rated load under forced air cooling.
A complete temperature protection and control system is equipped to ensure reliable and safe operation of the transformer.
It boasts high reliability. Statistics from field-operated products confirm its reliability indicators have reached top international standards.


在此添加您的标题文本

Technical Date of SCB10 Series
SCB10-50~2500/35 Epoxy-resin Dry-type Transformer
Rated capacity
(kVA)		 Rated voltage and tapping range Vector group No load
Losses (W)		 On load
Losses (W)		 Short-circuit
Impedance (%)		 No load
Current (%)
HV HV tapping range LV
50 35-38.5 ±5%
±2×2.5%		 0.4 Yyn0
Dyn11		 500 1500 6.0 2.8
100 700 2200 2.4
160 880 2960 1.8
200 980 3500 1.8
250 1100 4000 1.6
315 1310 4750 1.6
400 1530 5700 1.4
500 1800 7000 1.4
630 2070 8100 1.2
800 2400 9600 1.2
1000 2700 11000 1.0
1250 3150 13400 0.9
1600 3600 16300 0.9
2000 4250 19200 0.9
2500 4950 23000 0.9
SCB10-50~2500/20 Epoxy-resin Dry-type Transformer
SCB10-30~2500/10 Epoxy-resin Dry-type Transformer
Rated capacity
(kVA)		 Rated voltage and tapping range Vector group No load
Losses (W)		 On load
Losses (W)		 Short-circuit
Impedance (%)		 No load
Current (%)
HV HV tapping range LV
50 20
22
24		 ±5%
±2×2.5%		 0.4 Yyn0
Dyn11		 380 1300 6.0 2.4
100 600 2100 2.2
160 750 2600 1.8
200 820 3100 1.8
250 940 3600 1.6
315 1080 4300 1.6
400 1280 5100 1.4
500 1500 6100 1.4
630 1700 7200 1.2
800 1950 8700 1.2
1000 2300 10300 1.0
1250 2650 12150 1.0
1600 20
22
24		 ±5%
±2×2.5%		 0.4 Yyn0
Dyn11		 3100 14600 8.0 1.0
2000 3600 17250 0.8
2500 4300 20400 0.8
2000 3600 18800 0.8
Rated capacity
(kVA)		 Rated voltage and tapping range Vector group No load
Losses (W)		 On load
Losses (W)		 Short-circuit
Impedance (%)		 No load
Current (%)
HV HV tapping range LV
30 6
6.3
6.6
10
10.5
11		 ±5%
±2×2.5%		 0.4 Yyn0
Dyn11		 190 710 4.0 2.4
50 270 1000 2.4
80 370 1380 1.8
100 400 1570 1.8
125 470 1850 1.6
160 540 2130 1.6
200 620 2530 1.4
250 720 2760 1.4
315 880 3470 1.2
400 980 2990 1.2
500 1160 4880 1.2
630 1340 5880 1.0
630 1300 5960 1.0
800 1520 6960 6.0 1.0
1000 1770 8130 1.0
1250 2090 9690 1.0
1600 2450 11730 1.0
2000 3050 14450 0.8
2500 3600 17170 0.8
1600 2450 12960 8 1
2000 3050 15960 0.8
Amorphous Alloy Transformer
Model Voltage combination Connection
symbol		 No-load
loss (W)		 Load(w)
120°C (B)		 No load
Current %
HV(kV) HV tap LV(kV)
SCBH15-100 6
6.3
6.6
10
10.5
11		 ±2×2.5%
±3×2.5%		 0.4 Dyn11
Yyn0		 130 1570
SCBH15-160 170 2125
SCBH15-200 200 2525 0.8
SCBH15-250 230 2755 0.8
SCBH15-315 280 3470 0.7
SCBH15-400 300 3985 0.7
SCBH15-500 360 4880 0.6
SCBH15-630 420 5875 0.5
SCBH15-800 480 6955 0.5
SCBH15-1000 550 8125 0.4
SCBH15-1250 660 9690 0.4
SCBH15-1600 750 11730 0.4
